Description
Features:
- 400 tests per hour.
- 90 Reagent positions.
- 120 Reaction cuvettes.
- Built-in sample barcode system optional.
- 60 Sample positions(90 sample positions optional).
- Probe with anti-collision function, liquid level detection function.
Models：
| Model | BK-400 | |
|
Overall Performance |
Throughput | 400 Test/hour |
| Analysis Method | End-point, Fixed-time, Rate(Kinetic), Turbidimetry | |
| Certification | CE, FDA, ISO9001, ISO14001, ISO13485 | |
|
Sample & Reagent System |
Sample Positions | 60 or 90 sample positions, built-in barcode system available |
| Reagent Positions | 90 refrigerated reagent positions | |
| Sample Volume | 2-70μL | |
| Reagent Volume | 20-350μL | |
| Probe | Teflon coating, with anti-collision function,liquid level detection function | |
| Probe Washing | Automatic washing interior and exterior | |
| Reagent Cooling | 2~8℃ | |
|
Reaction System |
Temperature Control | 37±0.1℃, real-time monitoring |
| Cuvettes | 120reusable cuvettes, optical length 6mm | |
| Mixer Probe | Independent stirring | |
| Washing | Automatic cuvettes washing | |
| STAT function | YES | |
| Optical System | Light Source | 12V/30W halogen-tungsten lamp |
| Spectrophotometry | Post-spectral spectrophotometry | |
| Wavelength | 340,405,450,480,505,546,570,600,630,700,750,800nm | |
| Absorbance | 0~3.5Abs | |
| Calibration & QC | Calibration |
Linear:K factor, 1-point ,2-point and multipoint linear Non-Linear:Spline,Polygon, Index, Ogarithm, Logit-4P, Logit-5P |
| Quality Control | Real-time QC, Westgard multi rule, Cumulative Sum Check,Twin Plot(2D) | |
| Data Management | Software | Windows 7/8/10 , 32or 64bit |
| LIS System | Bi-direction,support HL7 protocol | |
| Interface | LAN port access | |
| Printer | External,multiple reporting mode available | |
| Working Conditions | Power Supply | AC220V±10%,50/60Hz, 110V±10%,60Hz, 500W |
| Temperature | 15～30℃ | |
| Water Consumption | Deionized water:10L/H | |
| Humidity | 40-85% | |
| Size & Weight | External Size (W*D*H) | 1170*775*1145mm |
| Net Weight | 190kg | |
| Package Size (W*D*H) | 1348*928*1377mm | |
| Gross Weight | 257kg | |
